Plastic Hanger Injection Mold
High-cavitation injection mold for plastic clothes hangers, supporting garment industry and household product production with efficient multi-cavity layout.
Project Notes
- Plastic hanger molds require high-cavity design with balanced filling, consistent dimensions, smooth surface finish and metal hook integration options.
- Engineering review covers hanger design, hook shape, shoulder profile, clip or notch features, cavity quantity and cycle time optimization.
- Suitable for suit hangers, shirt hangers, pant hangers, clip hangers and specialty garment hanger mold projects.
Basic Information
- Application: clothes hanger
- Process: injection molding
- Material: PP / PS / ABS / recycled
- Cavity: multi-cavity (4-24+)
What this mold project needs to solve
Plastic hangers are among the most cost-sensitive injection molded products. Multi-cavity molds producing consistent parts at fast cycle times are essential for competitive production. Hanger design ranges from simple wire-replacement shapes to complex designs with clips, notches and non-slip features.
Shengqi reviews the hanger design including overall shape, hook profile, shoulder width, bar length, clip or notch design, non-slip surface features and any metal hook overmolding requirements before mold design.
For high-volume hanger production, the mold must balance tooling cost, cycle time, material usage and part quality. Recycled material compatibility may also be a consideration.
Key points reviewed before tooling
Hook and Load-Bearing Design
The hook area bears the garment weight. Wall thickness, rib reinforcement and material flow at the hook-to-body transition are reviewed for strength and molding quality.
High-Cavity Runner Balance
Multi-cavity hanger molds require precise runner balancing. Naturally balanced layouts with equal flow distance to each cavity ensure consistent part weight and dimensions.
Surface and Edge Quality
Hangers must have smooth surfaces and rounded edges to avoid snagging garments. Mold polishing, parting line position and gate vestige control are quality points.
Metal Hook Insert Molding
Some hangers use metal hooks insert-molded into a plastic body. Insert positioning, material bonding and cycle time for insert loading are considered in mold design.
Information that helps Shengqi review the project
- Hanger design drawing with hook and dimensions
- Material, color and any recycled content requirements
- Metal hook or insert specifications if applicable
- Target cavity quantity and annual production volume
- Weight target, stacking or packaging requirements
