Automotive Lamp Injection Mold
Custom injection mold for automotive lighting components including lenses, housings, reflectors and bezels with optical surface requirements.
Project Notes
- Automotive lamp molds require optical-grade surface finish, precise dimensional control and heat-resistant material processing.
- Engineering review covers lens clarity, reflector geometry, housing assembly fit, bulb mounting points and sealing groove design.
- Suitable for headlamps, tail lights, fog lamps, turn signals and interior lighting mold projects.
Basic Information
- Application: automotive lamp parts
- Process: injection molding
- Material: PC / PMMA / ABS / PP
- Surface: optical / Class A
What this mold project needs to solve
Automotive lighting components include transparent lenses, metallized reflectors, black housings and decorative bezels. Each component has different mold requirements – lenses need optical clarity and UV resistance, reflectors need smooth surfaces for metallization, and housings need heat resistance and assembly precision.
Shengqi reviews lamp component drawings, material specifications, optical requirements, assembly interfaces and regulatory standards before mold design.
Automotive lamp molds often require multi-step processing after molding, including metallization, hard coating, hot plate welding and leak testing. The mold design considers these downstream processes.
Key points reviewed before tooling
Optical Surface Quality
Lens molds require diamond-polished cavities, controlled gate position away from optical zones and careful venting to avoid flow marks, splay or bubble defects on transparent surfaces.
Heat and UV Material Processing
PC and PMMA materials require specific drying, melt temperature and mold temperature control. The mold design includes optimized cooling and thermal management for these materials.
Assembly Fit and Sealing
Lamp housings must fit precisely with lenses and vehicle body panels. Sealing grooves for adhesive or gasket application require tight tolerance control.
Multi-Component Mold Coordination
When multiple lamp components are produced, the molds should be coordinated for consistent material, color and fit across the full lamp assembly.
Information that helps Shengqi review the project
- 3D drawings of lamp components with optical surface callouts
- Material specification and any regulatory standards
- Surface finish requirements (polish level, texture grade)
- Assembly and sealing interface details
- Expected quantity, mold life and delivery timeline
